Newly designed central air conditioning fin evaporator for refrigeration equipment

FOB Reference Price:Get Latest Price
US $51-55 / Pieces | 100 Piece/Pieces air conditioning evaporator (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China (Mainland)
Brand Name:
TianYang
Model Number:
air conditioning fin evaporator
Type:
Evaporator
Application:
Refrigeration Parts
Certification:
CE
Color:
Silver
Refrigerant:
R-134a
Product name:
air conditioning evaporator
Name:
air conditioning evaporator
Material:
copper
Tube material:
copper tube
Fin material:
Hydrophilic foil
Brand:
TianYang
Model:
Customer's Drawing
SupplyAbility
SupplyAbility:
180413 Piece/Pieces per Month air conditioning evaporator
Packaging & Delivery
Packaging Details
Packaging Details: Standard export carton
Delivery Detail: 15 days after received deposit
air conditioning evaporator
Port
Qingdao or Tianjin
Lead Time :
Shipped in 15 days after payment
Product Description

Newly designed central air conditioning fin evaporator for refrigeration equipment


Our main products including Fin-tube heat exchanger ,condenser, evaporator ,and radiator, which are widely used in air conditioner, refrigeration products such as refrigerator, freezer ,display cabinet, water dispenser and conditioner in transportation equipments .

1) We can supply it according to your drawings or samples, and we can also design according to your needs.

2) We have exported to many countries such as Pakistan, United States, New Zealand, etc.

3) Design terms: We have a professional technical team.

4) Professional Factory: We are a professional manufacturer of condensers, evaporators, heat exchangers and radiators for over 20 years, with competitive prices, and quality manufacturers.

5) Big productivity: 5,000 per month.

6) Respond quickly to your needs: We will reply within 24 hours after receiving your letter. If you have an emergency, please call us.

7) The most efficient service, best quality and good reputation.


8)Special-purpose products, please contact me

9)
Prices are for reference only!


Copper   tube           diameter (mm)
Hole distance(mm)
Row Space(mm)
Fin specifications
Pitch of fine(mm)
∅7(inside0.33, thread 26*17)
19.1
16(triangle)
Aluminum-copper fins, hydrophilic foil, white aluminum foil, water ripple or flat sheet
1.5 - 2.5
ф7 (flat tube 0.3mm)
21
12.7(Universal)
Aluminum-copper fins, hydrophilic foil, white aluminum foil, water ripple or flat sheet
1.5 - 2.5
∅7
21.8
20(triangles)
Aluminum-copper fins, hydrophilic foil, white aluminum foil, water ripple or flat sheet
4 about
ф9.52*0.28~0.35
25
21.65 (metric triangle)
Aluminum-copper
fins,hydrophilic foils, corrugated
2.2 - 5.5
∅9.52
25.4
22 (English triangular low flange)
Aluminum-copper
fins,hydrophilic foils, corrugated or windowed sheets
1.8 - 2.2-3
∅9.52
25
25(Square)
Aluminum copper fins, water ripple
3.5- 4.5
∅12
38
32.91
Aluminum-copper fins, hydrophilic foils, corrugated
5 - 8.5
∅12.7*0.39
31.75
27.5(Triangle)
Aluminum copper fins, water ripple
4.5 - 7
∅16*0.36
38
32.91(Triangle)
Aluminum copper fins, water ripples or flat films
5.5 - 8
∅16*0.36
55
27.5(Triangle)
Aluminum copper fins, water ripple
5.5 - 7.5
∅9.52 coil type
Mold diameter 9.52, outside garden 100mm.
  Material: copper tube copper fin, copper tube copper fin, aluminum tube aluminum fin (0.18mm-0.22mm), fins width 38
External brass diameter: 19mm, 22mm, 28mm. (Excluding special requirements)
The diameter of the hood: 210mm, 260mm 310 (300)mm, all of which are flanged, 240mm without flange.
End plate (1-1.2mm); Aluminum plate or galvanized plate, stainless steel plate
